0-12" DIAL HEIGHT GAGE . .0001" graduation. .100" dial revolution. Adjustable dial for easy zero settings.
Made of hardened stainless steel with black bar graduations on a satin chrome finish. Comes with carbide tipped scribe,clamp and wooden case.
0.4" TO 0.7" DIAL BORE GAGE SET
.
2.4 bore depth
9 anvils
This dial-type cylinder bore gauge set has a 2" to 6" range that can cover most motorcycle and automotive engines. Don't even think of buying a used engine block or jugs for your bike without using one of these babies to check things out first.
Comes with fitted carrying case.
Graduation: 0.0005"
MVB0537 V-Block Pecision Set Clamping
Made of tool steel, hardened and precision ground.
Matched and numbered in pairs to an accuracy of .0002"
Capacity: 1 1/2" . Size: 2 3/4" x 1 3/4" x 1 5/8"
AO645187 1.4 TO 2.4 DIAL BORE GAGE SET
6 bore depth. 6 anvils. This dial-type cylinder bore gauge set has a 2" to 6" range that can cover most motorcycle and automotive engines. Don't even think of buying a used engine block or jugs for your bike without using one of these babies to check things out first. Comes with fitted carrying case. Graduation: 0.0005"
- 2-6" inch range
- 6" bore depth
- 3pc washers and 11 pc Anvils (1 anvil installed in the bore gage probe and 10 pc in case slot)，No product for two slots is correct.
- Size includes: 4.0'', 3.8'', 3.6'', 3.4'', 3.2'', 3.0'', 2.8'', 2.6'', 2.4'', 2.2'', 2.0''
- Grad. 0.0005“ Self-centering measuring heads, chrome plated handle and includes extension holder and good quality fitted case
26 Pc. Precision Radius Gage Set SAE
Five different gauging surfaces on each gage for both convex and concave radius.
Made of satin finish stainless steel-rust and stain resistant
With handy gage holder.
.010-0.500" . 1/64"-17/64" x64ths.
9/32"-1/2" x 32nds
36 Pc. Round Space Block Set has the following specifications:
- Overall Diameter: 3/4″
- Accuracy: +/-0.0001
- 36 Blocks included
- Working surfaces hardened to Rc 57-60
- Individually marked
Features:
- Packaged in a high quality fitted case
- For quickly setting stops and setups on lathes, milling machines and drill presses, setting sine bars, etc.
- Size marked on each block.
- Overall diameter is 3/4″ and ID is threaded: 6mm x 1.0mm Working surfaces hardened to RC 58-60.
- Surfaces precision ground and lapped to tolerances shown.
- Four connecting screws supplied to form whatever length is desired.
- Furnished in plastic case
The following blocks are included in this set:
- .050, .060, .0625, .070, .080, .090, .100, .101, .102, .103
- .104, .105, .106, .107, .108, .109, .110, .120, .125, .130
- .140, .150, .160, .170, .180, .190, .200, .300, .400, .500
- .600, .700, .800, .900, 1.00 (2 ea.)
36PC SPACE BLOCK SET 36 Pc Space Block Set Hardened To 57 - 60 Rockwell NEW Work surface hardened to Rc 57-60 Accuracy ±0.0001” Four connecting screws are included to make any length desired Made of precision tool steel Individually marked Meets or exceeds federal specifications
Fitted case 9 Blocks: 0.101 to 0.109 in 0 .001” steps 15 Blocks: 0.050 to 0.190 in 0.010” steps 9 Blocks: 0.200 to 1.000 in 0.100” steps 2 Blocks: 0.0625” and 0.125” 1 Extra Block: 1.000"
FEATURES:
- Hardened to 65 RC.
- Manufactured in a controlled environment to ensure accuracy.
- Meets or exceeds federal spec ASME B89.1.9-2002.
- Workshop grade B without certificate.
- Surface finish: .4 millionths (.01 microns).
- Includes fitted case.
SET INCLUDES:
1 Block: .050"
10 Blocks: .1000-.1009" in .0001" steps
9 Blocks: .101-.109" in .001" steps
9 Blocks: .110-.190" in .010" steps
4 Blocks: .200-.500" in 1.00" steps
3 Blocks: 1, 2, 4"
FEATURES:
- Measures the True Sizes of Holes, Slots and Recesses from 5/16" - 6"
- Contact Plungers Automatically Self-Center at All Times and in All Positions
- Plungers Locked in Any Desired Setting
- Locking Mechanism Consists of a Knurled Screw at the End of the Handle
- Available as Individual Gages or in Sets
- Satin Chrome Finish
- Contact Ends are Hardened and Radius Ground Providing Clearance for Insertion into the Smallest Hole the Gages will Enter
SPECS:
- Measuring Range: 5/16" - 6", 6pcs (1 x 1/2" to 3/4"; 1 x 2-1/8" to 3-1/2"; 1 x 3/4" to 1-1/4"; 1 x 3-1/2" to 6"; 1 x 5/16" to 1/2"; 1 x 1-1/4" to 2-1/8")
- Unique Design: Contact points are made of hardened tool steel, ends are precision ground for radius measurement, and a rigid handle with self-centering system allows quick inspection of internal dimensions
- High-Quality Material: The telescoping gage set is made of rust-proof steel material, nickel-plated surface, with good side arc, strong and durable, effectively prolonging the use time
- High Performance: The spring tension of the t bore hole gauge is constant, and the hand feel is uniform and smooth, which can not only ensure accurate measurement, but also improve your experience
- Easy to Carry: We provide you with a suitable plastic bag case for easy storage and effectively avoid product damage
